RHRG75120 Hyperfast DiodeThe RHRG75120 is a hyperfast diode with soft recovery characteristics (trr < 85ns). It has half the recovery time of ultrafast diodes and is silicon nitride passivated ion-implanted epitaxial planar construction. This device is intended for use as a freewheeling/clamping diode and rectifier in a variety of high frequency switching power supplies and other power switching applications. Its low stored charge and hyperfast soft recovery characteristic minimize ringing and electrical noise in many power switching circuits, thus reducing power loss in the switching transistors. RHRG75120 IC Specifications: Manufacturer ON Semiconductor Product Category Diodes - General Purpose, Power, Switching Mounting Style Through Hole Package/Case TO-247 Peak Reverse Voltage 1200 V Configuration Single Recovery Time 100 ns Vf - Forward Voltage 3.2 V Ir - Reverse Current 250 uA Maximum Operating Temperature + 175 C Series RHRG75120
